There’s nothing like a subwoofer or two for adding major bass kick to any factory sound system. The JBL

MS-A5001 is

a compact amplifier with 500 watts of power and outputs to connect up to two subwoofers in parallel. It accepts any

line-level or speaker-level output, and features onboard setup tools for easy, foolproof installation. A digital input mixer

lets you map your inputs to either output, and sophisticated network circuitry puts you in precise control of the crossover

points and slopes. Serious bass is an essential element of any great car audio system, and the MS-A5001 delivers it

with easy precision.

SPECIFICATIONS

Manufacturer: HARMAN International Industries, Incorporated

Model: MS-A5001

Power output (CEA 2006): 500W RMS x 1 @ 4 ohms

500W RMS x 1 @ 2 ohms

Frequency response: 20Hz – 270Hz

Signal-to-noise ratio: >80dB (1W)

>106dB (full power)

Maximum input sensitivity: 100mV

Maximum input voltage: 20V

Power requirement: 12V DC, negative ground

Main unit dimensions (L x W x H): 7-3/16" x 8-1/4" x 2-3/4" (183mm x 210mm x 70mm)

Weight: Approximately 5.2 lbs (2.5kg)

MS-A5001

Digital signal processing amplier

1 2

MS-A5001 1
